轴承型号	基本尺寸			基本额定载荷		疲劳载荷极限	额定转速	Limiting
	Principal dimensions			动态	静态		参考转速
Bearing	d / d1	D	B	C	C0	Pu	r	speed
	mm			kN		kN	min
C2206KTN9+H306E	25	62	20	69.5	62	7.2	11000	15000
C2207KTN9+H307E	30	72	23	83	80	9.3	9500	13000
C2206TN9	30	62	20	69.5	62	7.2	11000	15000
C2206KTN9	30	62	20	69.5	62	7.2	11000	15000
C6006V	30	55	45	134	180	21.2		3200
C2206V	30	62	20	76.5	71	8.3		6000
C2207KTN9	35	72	23	83	80	9.3	9500	13000
C2207V	35	72	23	95	96	11.2		5300
C2208KTN9+H308E	35	80	23	90	86.5	10.2	8000	11000
C2208KTN9+AH308	35	80	23	90	86.5	10.2	8000	11000
C2207TN9	35	72	23	83	80	9.3	9500	13000
C2208KTN9	40	80	23	90	86.5	10.2	8000	11000
C2209KTN9+AH309	40	85	23	93	93	10.8	7500	11000
C2208TN9	40	80	23	90	86.5	10.2	8000	11000
C2208V	40	80	23	102	104	12.2		4500
C2209KTN9+H309E	40	85	23	93	93	10.8	7500	11000
C4908V	40	62	22	76.5	100	11.8		4300
C2209KTN9	45	85	23	93	93	10.8	7500	11000
C6909V	45	68	40	132	200	23.6		2600
C2209TN9	45	85	23	93	93	10.8	7500	11000
C2210KTN9+AHX310	45	90	23	98	100	11.8	7000	9500
C2210KTN9+H310E	45	90	23	98	100	11.8	7000	9500
C2209V	45	85	23	106	110	12.9		4300
C2211KV+AHX311	50	100	25	132	134	15.6		3400
C2210KTN9	50	90	23	98	100	11.8	7000	9500
C2211KV+H311E	50	100	25	132	134	15.6		3400
C6910V	50	72	40	140	224	26		2400
C2211KTN9+AHX311	50	100	25	116	114	13.4	6300	9000
C2211KTN9+H311E	50	100	25	116	114	13.4	6300	9000
C4910V	50	72	22	86.5	125	14.6		3600
C4010TN9	50	80	30	116	140	16.3	5600	7500
C4010V	50	80	30	137	176	20.8		3000
C2210TN9	50	90	23	98	100	11.8	7000	9500
C2210V	50	90	23	114	122	14.3		3800
